OPNsense Suricata IDS/IPS: Installation and Tuning Guide

Suricata is OPNsense’s built-in network IDS/IPS engine. Running it inline (IPS mode) drops malicious traffic in-band. This guide covers setup from scratch through basic tuning.

Hardware requirements

Suricata is CPU-intensive. Inline IPS on a 1 Gbps WAN needs at least:

• 4-core CPU (Intel J6412 or better)
• 4 GB RAM dedicated to OPNsense
• Multi-queue NIC drivers (most Intel i210/i225 cards)

On a Protectli FW4C (J3160), expect ~250–400 Mbps throughput with ET Open rules before CPU saturation.

Install the plugin

System → Firmware → Plugins → search os-suricata → Install.

After install: Services → Intrusion Detection → Administration.

Configure interfaces

On the Settings tab:

• Enabled: ✓
• IPS mode: ✓ (inline — drops matching traffic, not just alerts)
• Promiscuous mode: leave unchecked unless you need it
• Interfaces: select your WAN interface (and LAN if you want east-west inspection)
• Pattern matcher: Hyperscan if available (faster), otherwise AC-BS

Enable rulesets

On the Download tab:

Ruleset	Cost	Notes
ET Open	Free	Good baseline, delayed vs ET Pro by 30 days
ET Pro	~$600/yr	Real-time, full threat intel
Abuse.ch SSL Blacklist	Free	SSL cert-based C2 detection
Abuse.ch URLhaus	Free	Malware URL blocking

Enable ET Open + both Abuse.ch feeds for a free starting point. Click Download & Update Rules.

Alert vs Drop

Rules have two modes:

• Alert — log the event, pass the traffic
• Drop — block the traffic immediately (IPS mode only)

Start with Alert for 1–2 weeks, review the alert log, then move clean-looking rules to Drop.

Tuning false positives

In the Rules tab, filter by SID to suppress noisy rules:

# Common high-noise rules to review first:
ET POLICY DNS Query to .TK domain
ET POLICY Dropbox Client Observed
ET INFO Executable Download

For known-good internal services triggering rules: add a passlist (Intrusion Detection → Passlist).

Monitoring alerts

Services → Intrusion Detection → Alerts. Key columns: timestamp, SID, severity, source/dest IP.

For persistent monitoring, ship logs to Grafana/Loki or a syslog target (System → Settings → Logging).
